The Turnigy TrackStar 1/10th scale 100amp car ESC is the latest addition to Hobby Kings Sensored Car ESC range.
Using a Fast Silicon Labs MCU and high quality On-Semiconductor MOSFETs the TrackStar 100A ESC sets a new standard in high quality yet affordable car ESCs. With Intelligent MCU logic the TrackStar series ESCs allow extremely precise start up control and positioning feed back from the motor. This translates in to very smooth start up and acceleration.
Timing Indicator LED.
To conform with ROARs Sportsman Class racing rules and assist race organizers monitor driver compliance in non-timing modified race classes the TrackStar 1/10th ESC includes a timing mode indicator LED. At all times when the ESC is powered on and dynamic motor timing is set to a value greater than zero the white LED will illuminate indicating that the timing mode has been modified.
The Turnigy TrackStar 100A ESC also boasts a host of programing options not usually found in a 1/10th scale ESC at this price and can be programmed with ease via the Turnigy TrackStar programing card (sold separately) The Turnigy TrackStar 100A ESC also included 3 x 12AWG Motor wires and 2 x 12AWG power input wires.
Specification:
Cont. Current: 100A
Burst Current: 200A
Car Size: 1/10th
Battery: 2-3 Cell Lipo
L-BEC: 5.0V / 2A Output
Motor Type: Sensored or Sensorless Brushless
Size: 40.5 x 37.5 x 24mm
Weight: 45g
Battery Plug: Required
On/Off Switch: Yes
Reverse: Yes
Thermal Overload Protection: Yes
Battery Terminals: 12AWG size
Motor Terminals: 12AWG size
Programming Options (Via Optional programming card)
Brake/Reverse type
Brake amount
Reverse amount
Punch Control
Drag Brake
Throttle Dead Band
Voltage Cut off
Motor Timing
NEW! Motor Reversing (v2.0 software)
