Compatible with Super Narrow Pulse (760µs) drive. Specification:
Dead band: 0.0008ms (Default)
Control System: +Pulse Width Control
Working frequence: 1520μs / 333hz
(RX) Required Pulse: 3.5 ~ 6.0 Volt Peak to Peak Square Wave
Operating Voltage: 4.0 ~ 6.0 V DC Volts
Operating Temperature Range: -10 to + 60 Degree C
Operating Speed (4.8V): 0.14 sec/60° degrees at no load
Operating Speed (6.0V): 0.12 sec/60° degrees at no load
Stall Torque (4.8V): 9.2 kg.cm (127.8 oz/in)
Stall Torque (6.0V): 11.5 kg.cm (159.7 oz/in)
360° Modifiable: NO
Motor Type: Brushless Motor
Potentiometer Drive: Indirect Drive
Bearing Type: Dual Ball Bearings
Gear Type: Titanium Gears
Programmable: NO @
Connector Wire Length: 24.0 cm (9.4 in)
Dimensions: 40 x 20 x 40 mm ( 1.57x0.79x1.50 in)
Weight: 55.8 g (1.96 oz)
