Spec: Main Rotor Diameter:970-1040mm
Tail Rotor Diameter:210-222mm
Length (with canopy) :900mm
Height :320mm
Width :165mm
Main Blades Length:425-460mm
Tail Blade Length:70-77mm
Weight: 1780g
Gear Ratio :6.67 :1:4.36 (18T Pinion)
Battery Bay :6s 2200-5000 mAh
Servos: Mini Servos
More PhotosGAUI X4II Electronic Equipment Reference Table Servos：Mini Servos（500 size）Normal 3D Fly：GAUI GS511，Hitec 5245 MG, Align DS510M/DS515M, Savox SH1250, Graupner DES 678 MG, MKS DS-9660A+, Futaba 9650
Hard 3D Fly：GAUI GS303(HV BLS)，ServoKing 795HV，Futaba BLS153, Graupner HBS660 HV, JR DS3717 HV, HITEC 7245 MG HV, JR DS3711 HV
Rudder Servo: Low V：GAUI GS518，Savox SH1257，MKS DS8910A+，Align DS520M/DS525M
High V：GAUI GS304，ServoKing 795i
Speed Control：66～100A，6S Input Normal 3D Fly：GAUI GE-602，HobbyWing 80A
Hard 3D Fly：GAUI GE-610，HobbyWing 100A，Kontronik Koby90A，YGE 80 LV, CC Talon 90A
Brushless Motor Size: Wide Size：48mm
KV Range 900KV～1400KV
How to count：Main Gear：120T
Battery Input：22.2V
Motor Efficiency：90％
Motor Brand KV Pinion K/YGE GAUI/HobbyWing Gov Main Blades RPM
GM-601-910KV 18T Gov@80％ 73％@Gov High 2800rpm
Scorpion HKIII-4020-1100 15T Gov@80％ 84％@Gov High 2800rpm
Scorpion HK4015-1070 15T Gov@85％ 78％@Gov High 2800rpm
Scorpion HK3026-1400 13T Gov@65％ 87.5％@Gov High 2800rpm
Scorpion HK3226-900 18T Gov@80％ 79.5％@Gov High 2800rpm
Scorpion HK3226-1400 13T Gov@80％ 87.5％@Gov High 2800rpm
Battery Max Size:（W46mm × H73mm × L180mm）
6S 2600~50000 mAh 22.2V
Gyro Max Size Aera：16mm*38mm*38mm
Suggest :Vbar、MiniVbar、Skookum SK720、SK540、Microbeast BeastX、Futaba CGY750
